• H12 - Inappropriate device capacities
  • H15 - Fault with compressor temperature sensor
  • H20 - Fault with circulation pump
  • H23 - fault with coolant sensor
  • H27 - Fault with service valve
  • Н28 - Fault with solar sensor
  • Н31 - fault with swimming pool sensor
  • Н36 - Fault with buffer tank sensor
  • Н38 - Fault due to non-matching device brands
  • Н42 - Low pressure protection
  • Н43 - Fault with the sensor for heatC 1
  • Н44 - Fault with the sensor for heatC 2
  • Н62 - Fault with upstream with the flow monitor
  • Н63 - Fault with the low pressure sensor
  • Н64 - Fault with the high pressure sensor
  • Н65 - Fault with the water circulation during defrosting
  • Н67 - Fault with outdoor temperature sensor 1
  • Н68 - Fault with outdoor temperature sensor 2
  • Н70 - Fault with overload protection for indoor units E-heating element
  • Н72 - Fault with hot water tank temperature sensor
  • Н74 - Fault with the PCB communication
  • Н75 - Low water temperature protection
  • Н76 - Fault with the PCB communication
  • Н90 - Communication
  • Н91 - Fault with overload protection for hot water E-heating
  • Н95 - Fault with incorrect voltage IU - OU
  • Н98 - Fault due to high pressure protection
  • Н99 - Fault due to frost protection of indoor units heat exchanger


  • F12 - High pressure switch in the outdoor unit triggered
  • F14 - Incorrect compressor speed
  • F15 - Incorrect speed of the OU fan motor
  • F16 - Fault due to excessive current consumption
  • F20 - Fault due to overload protection of the compressor
  • F22 - Fault due to overload protection of power transistor
  • F23 - Fault due to direct current peaks in the OU
  • F24 - Fault due to problems in the cooling circuit
  • F25 - *1 Fault due to problems with the switching interval
  • F27 - Fault with the high pressure switch in the OU
  • F29 - Low hot gas superheat
  • F30 - Fault with the inflow temperature sensor
  • F32 - Fault with with the room thermostat
  • F36 - Fault with the outdoor temperature sensor
  • F37 - Fault with  the return flow temperature sensor
  • F40 - Fault with the hot gas temperature sensor in the outdoor unit
  • F41 - Error in the power factor correction
  • F42 - Error with the heat exchanger sensor in the outdoor unit
  • F43 - Fault with hot gas temperature sensor in the outdoor unit
  • F45 - Fault with the defrost temperature sensor in the outdoor unit
  • F46 - Current transformer switching off
  • F48 - Error with evaporator outlet temperature sensor
  • F49 - Fault with bypass outlet temperature sensor in the OU
  • F95 - *1 Fault due to HP protection cooling in the outdoor unit
*1 - The system is preset for operation without a cooling function. The cooling function can be activated by an authorised installer or service partner.
